The FMDX range of High Performance Log Periodic Dipole Arrays

If you are looking for the best of the best from both a performance and mechanical construction perspective then look no further, you have come to the right place!

Improved Performance

The FMDX-9 is one of 3 brand new Log periodic designs. These arrays have been designed to be strong, light weight and most important of all, to give unparalleled performance from a low-profile package for FM band DX'ing.

Multiband, Performance-Busting Design

This antenna has all elements made from 1/2inch aluminium thick wall tube. The parasitic elements are also 1/2inch. All elements are electrically connected to the boom held in place by marine grade stainless steel components. The boom is 3/4'' inch square (19.05mm) which is in 3 sections. two sections of boom form the feedline and antenna element support, the third section provides a boom support truss. If you want an antenna to last and perform in all weathers without SWR or bandwidth shifting, this is it.

The FMDX range provide all the benefits of the concentrated element array with multiple reflectors in a single-plane, low-profile and light weight package. In addition to the superior electromagnetic design, as with all antennas, it is build of the highest quality with marine grade stainless steel being used throughout.

Technical Specification:

• Typical Gain: 9.5dBi
• Typical F/B: 33dB
• Gain at 10m (33') above ground: 15.58dBi
• Power Rating: 3kw
• Feed Impedance: 75 Ohm or 50Ohm
• Boom Length: 4.1m - 13'5''
• Weight: 2.82Kg / 6.21LB
• Turning Radius: 1.903m / 6.24ft
• Wind Loading: 0.02 Square Metres / 0.56 Square feet
• Wind Survival: 150PH / 90MPH
