8 element 144MHz LFA Yagi

The LFA Yagi has quickly become the one to have if you are looking for serious weak signal work on the bottom of the 2m band. The LFA Yagi has been specifically designed to ensure the lowest levels of unwanted noise are received.

The LFA loop along with the great pattern helps to ensure the very best user experience with the weakest signals being heard. The LFA is especially effective for EME where very low noise antennas are required and many hours development have been spent ensuring the highest levels of performance have been achieved.

The antennas are constructed with the best quality materials in order that the best mechanical construction can be achieved, even a digital caliper is used (with an accuracy of .01mm).

Specification

• Gain:13.32dBi @ 144.100MHz
• Gain: 13.34dBi @ 144.300MHz
• F/B: 25.76dB @ 144.100MHz
• F/B: 26.12dB @ 144.300MHz
• Peak Gain: 13.36dBi
• Gain at 10m above ground: 19.18dBi
• Peak F/B: 27.21dB
• Power Rating: 3kw
• SWR: Below 1.13.1 from 144.00MHz to 145.00MHz
• Boom Length: 3.729m
• Weight: 2.82Kg
• Turning Radius: 1.903m
• Wind Loading: 0.08 Square Metres
• Wind Survival: 331KPH
• Stacking Distance Vertically: 2.0-2.5m (best trade-off 2.40m)
• Stacking Distance Horizontally: 2.4-3.2m (best trade-off 3.15m)
• Sky Temperature: 257.4 Kelvin @ 144.100MHz
• G/T Figure: -4.72dB @ 144.100MHz
