9 element OWL-G/T (4.95m long)

Optimised Wideband Low Impedance Super-Light Yagi for 144-145MHz For horizontal mounting

The OWL has been designed to have very close element spacing, this has increased the stability of the OWL over traditional low impedance Yagi’s.

The OWL G/T has been designed to achieve high gain levels while still producing very respectable sky temperature figures. This combination has resulted in class-leading G/T performance begin achieved.

The antennas are constructed with the best quality materials in order that the best mechanical construction can be achieved, even a digital caliper is used (with an accuracy of .01mm) to measure the elements during production to ensure they are within 0.2mm.

This antenna is made with a 1/2inch (12.7mm) and 3/8inch (9.525mm) diameter tube OWL loop and 1/2inch (12.7mm) elements with a wall thickness of 1.2mm. Boom is 3/4inch.

Specification

• Gain: 14.74dBi @ 144.3MHz
• F/B: 22.68dB @ 144.3MHz
• Peak Gain: 14.23dBi
• Gain 10m above ground: 22.38dBi
• Peak F/B: 23.31dB
• Power Rating: 5kw
• SWR: Below 1.2:1 from 144MHz to 145MHz
• Boom Length: 4.95m
• Weight: 3.9kgs
• Safe Wind Speed: 127Mph
• Turning Radius: 2.29m
• Vertical Stacking: 3M
