MISSING USB CABLE

The Tecsun PL368 is a portable PLL DSP multiband receiver with SSB and Synchronous Detection. It introduces Tecsun's new ETM+ feature which gives the possibility of setting up time-specific memories for longwave, medium wave (AM) and shortwave.

Its compact size is ideal for travelling. Let the radio wake you up in the morning by setting the alarm or set the sleep timer to auto turn-off the device while listening before going to sleep.

Charge the battery by connecting the radio to a 5V USB charger, one similar to those used for most smartphones and tablets.

Specification

• Frequency Range: FM: 64-108 MHz (4 ranges selectable) | AM: 520 – 1710 kHz (Tuning step 9/10 KHz selectable) | LW: 153 KHz - 513 KHz | SW: 1711 HHz - 29999 KHz
• Tuning Methods: Direct keypad entry; Auto scan; Manual dial tuning
• Sensitivity: FM (S / N = 30dB) <3uV | AM (S / N = 26dB) <1mV/m | LW (S / N = 26dB) <10mV/m | SW (S / N = 26dB) <20uV
• Selectivity: FM > 60dB | AM / LW > 60dB | -SW > 60dB | SYNC lock range: +/- 1kHz
• IF Frequency (DSP): AM: 45 KHz | FM: 128KHz
• Output Power: Approx. 350mW
• Speaker (16Ω, 0.5W)
• Power: BL-5C lithium (Li-Ion) battery
• Charging: DC 5V / 500mA
• Dimensions: 6.38” x 2.09” x 1.02”
• Weight: 4.6 ounces

Included in Box

• PL368 Radio
• 3.7V/1000mAh rechargeable battery
• Carrying pouch
• Stereo earphones
• User manual in English
