Comet CAA-500 MARK II Standing Wave Analyzer 1.8-500MHz SWR & Impedance Simultaneously

The NEW CAA-500 MKII version SWR/Impedance Analyser now adds a full colour TFT LCD display to the original model whilst still featuring an analogue cross needles display for SWR and impedance.

Features

• Automatically graphs the SWR on the LCD display. Choose any one of the pre-set amateur band frequency ranges and press the sweep button in for about 30 seconds the SWR graph is completed and displayed.
• Choose the band and manually set the bandwidth and manually sweep the chosen frequency range.
• Should you want to make an adjustment to the antenna length, to the position, height above ground, a gamma match adjustment, etc- you can overlay 5 manual sweep results in different colours! Instantly graph and see exactly what happened after each adjustment!

Specification

• Range: 1.8 - 500 MHz
• RF output level: 0dBm 1 mW
• Measured SWR Range: Analogue meter 1.0 6.0:1, LCD display 1.0 9.9:1
• Impedance measurements: 12.5-300 Ohms
• Reactance range: 0 - 500 Ohms (absolute value) 1.8 -190 MHz
• Battery indicator and selectable Auto-Power-Off timer
• Operates up to 9 hours continuous using six AA Alkaline or NiMH cells (not included) or use an external 8-16VDC 200ma power source (DC cable included)
• Internal trickle charger option when using NiMH batteries
• Dimensions: 3.5 x 7.75 x 2.65 inches (overall)
• Weight: 2lbs 2oz with alkaline batteries installed
