USED, NO MANUAL AND MISSING INTERNAL PACKAGING

This Alinco DX-R8 from Alinco allows you to tune the world with SDR without breaking the budget. This 150 KHz to 30 MHz Desktop receiver has an IQ output which allows you to monitor AM/FM/SSB/CW signals either in a superhetrodyne Desktop radio or using your PC with free SDR software.  Listen to DRM Hi-fi broadcasts without a converter. PC-decode of HFDL, FAX, NAVTEX, RTTY, PSK and more.

Key Features/Specifications:

• Frequency range 0.15 - 35MHz
• Modes: AM / FM / CW / USB / LSB
• Frequency stability : ± 1 p.p.m.
• Sensitivity : AM 0.15-1.8 MHz: 10 µV, 1.8-30 MHz: 2 µV
• FM 28-30 MHz: 0.25 µV
• SSB 0.15-1.8 MHz: 1 µV
• CW 1.8-30 MHz: 0.25 µV
• Selectivity:
• AM Narrow 2.4 kHz (-6 dB), 4.5 kHz (-60 dB)
• AM/FM 6 kHz (-6 dB), 18 kHz (-60 dB)
• SSB/CW 2.4 kHz (-6 dB), 4.5 kHz (-60 dB)
• IF-frequencies:
• 1st: 71.75 MHz
• 2nd: 455 kHz
• Image rejection 70 dB
• Audio output :<2.0 W into 8 ohm 10% THD
• Memories :600 channels in 3 banks
• Power requirements : 11.7 - 15.8V DC
• Current drain 1 A max
• Dimensions (w×h×d): 240 × 100 × 293 mm (9.45 × 3.94 × 11.54 in)
• Weight:  4.1 kg (9 lbs)
