MFJ-705 - 2500 watts Low Pass TVI Filter
Suppress TV interference at the source with the MFJ-705 Low Pass Filter. Use between Transmitter and Antenna or Tuner. Reduces TV interference (TVI) radiated by transmitters operating below 30 MHz. Suppresses harmonics appearing in the TV bands. Additional attenuation to TV IF frequencies above 40 MHz.
- SKU
- 53-327
£173.18
Description / MFJ-705 - 2500 watts Low Pass TVI Filter
Suppress TV interference at the source with the MFJ-705 Low Pass Filter. Use between Transmitter and Antenna or Tuner. Reduces TV interference (TVI) radiated by transmitters operating below 30 MHz. Suppresses harmonics appearing in the TV bands. Additional attenuation to TV IF frequencies above 40 MHz.
Low loss to 30 MHz. 9-pole inverse Chebyshev.
SPECIFICATIONS:
- Passband: 0-30 MHz
- Cutoff freq: 35 MHz
- Attenuation: 52.25 MHz (Channel 2 Video), -60 dB, Worst case at 65 MHz, -60 dB
- Power Capacity: 2500 W Key Down - 50% Duty
- Impedance: 52 Ohms Insertion
- Loss: 0.25 dB @ 30 MHz.
- Size: 91/2Wx 21/4Hx41/4D inches.
More Information
| Allow Backorder in Clerk.io | No |
|---|---|
| Product Condition | New |
| Bar Code/EAN | 5056109229830 |
| Manufacturer | MFJ |
| Item returned for technician testing period | 14 days |
| Repair period | 90 days |
| Refund period | 14 days |
| Exchange period | 14 days |
